CEMB ER72SE Adaptive OPB Wheel Balancer with Touch Screen (Pneumatic Clamping)
- VENDOR:- CEMB
- SKU# ER72SE
CEMB ER73TD Adaptive OPB Wheel Balancer with Video Touch Screen
The CEMB Video Touchscreen Wheel Balancer ER73TD is made especially for busy tire shops. This new series has the latest technology in wheel balancing, “Spotter” lasers that actually pinpoints the exact location of stick-on wheel weights. This is done with little or no chance of operator error when entering dimensions (major cause of check spin errors).
Full Time Static on screen for a perfect balance. The automatic arm measures diameters up to 30″, automatic entry of the dimensions with width sonar 3D. It comes fully assembled.
The innovative tolerance calculation system AutoAdaptive Mode is based on the evaluation of the residual imbalance limit value corresponding to an acceptable perceived vibration. For each wheel that is balanced, the software AutoAdaptive Mode detects weight and dimensions and calculates the tolerance value that will cancel any vibration perceived on the steering wheel. AutoAdaptive Mode grants the highest comfort when driving, and together with OPB Program, saves balancing time.
One Plane Balancing
OPB (One Plane Balancing), eliminates both static and dynamic unbalance with a single counterweight, indicating the exact position to apply the weight inside the rim. The balancer automatically detects if it is possible to correct both unbalances with only one weight, and activates OPB program (One Plane Balancing). A real revolution in wheel balancing. OPB saves you time and money while maximizing your productivity.
During the correction, the LASER SPOTTER pinpoints the exact position for stick-on weights application inside the rim. Thanks to the electric brake – which locks the wheel into the exact angular position of the unbalance – and the laser spotter you avoid possible errors during the weight application making the balancing process faster, simpler and more precise.
- One Plane Balancing (OPB)
- AutoAdaptive™ Mode
- Automatic Approach
- Automatic Gauge (3D)
- Laser Spotter
- Manual Locking
- Width Sonar
- Electromagnetic Brake
- Power Supply 220V, 1ph, (Air for ER72SE)
- Wheel Clamping Type Manual / Pneumatic
- Max. Rim Diameter 30" (765 mm)
- Max. Rim Width: 20" (510 mm)
- Max. Tire Diameter: 42" (1067 mm)
- Max. Wheel Weight: 165 lbs. (75 kg)
- Shipping Weight: 300 lbs. (136 kg)
This Item Qualifies for FREE LTL SHIPPING (via Truck) it applies only to destinations within the 48 contiguous United States. Alaska, Hawaii, and any/all US territories and international orders are excluded.LTL Freight Shipping Options
- Lift Gate Is Required.(+$150.00)
- I have a forklift for unloading Freight at My Business location
- I have a way of unloading Freight at my location
- Deliver to local freight terminal for pickup.
Please select one of the choices above BEFORE adding to the cart!
This item ships by truck. If you Require to ship to a Non-Commercial Address, please email
or call (706) 478-0072 us so we can give you an updated shipping Quote.
