CPS Products VP12D VP12D Pro-Set 12 CFM A/C Vacuum Pump

Documents

CPS Products VP12D Pro-Set Two-Stage, Dual Voltage (115/230V) Vacuum Pump w/Gas Ballast Valve

MODEL# VP12D

The VP12D Pro-Set® 12 CFM vacuum pump is a powerful 2 stage unit with a versatile dual voltage 1HP motor. The unit boasts the same high quality, high value features engineered into all of our Pro-Set® Premium Series vacuum pumps providing performance excellence and years of reliable service.

VP12D Key Features:

• Dual voltage operation 110-120V / 220V 50/60Hz
• Exceptional ultimate vacuum rating as low as 10 microns
• Advanced air cooled motor design for operation in high ambient temperatures
• Proprietary oil mist free exhaust port cap for clean, safe job environment
• Gas ballast valve speeds achievement of deep vacuum
• Multiple port connections for ¼", ⅜" and ½" ACME
• Easy maintenance with large oil sight glass and fill port with easily accessible oil drain port.
• Solid rubber base provides extreme shock resistance
• Sure-grip handle ergonomically designed for superior comfort and portability

Specifications

• Stage: 2
• Motor Size (HP) RPM @ 50/60Hz: 1 (HP) 2880 / 3440
• Dimensions (Inches): 14.9 x 5.7 x 10.6
• Weight: 30.9 lb / 14.0 kg
• Operating Temperature Range: 0˚C (32˚F) to 52˚C (125˚F)
• Power Source: 110-120V / 220V 50/60Hz
• Ultimate Vacuum: as low as10 Microns
• Oil Capacity: 27 oz / 800 ml

Documents

CPS VP12D Product Manual
