ESCO 10381 Pro Series 20 Ton Air Hydraulic Bottle Jack
ESCO 10381 Pro Series 20 Ton Air Hydraulic Bottle Jack
Ships within (1 - 3 Business Days)
SKU: 10381
Couldn't load pickup availability
Description
ESCO 10381 Pro Series 20 Ton Air Hydraulic Bottle Jack
Model #10381
The ESCO Pro Series 20 Ton Air Hydraulic Bottle Jack is built for heavy-duty tire service applications. Designed for commercial truck, bus, tractor, and farm equipment use, it features a compact frame, chrome-plated piston, and fully welded cylinder construction for long-lasting durability. The jack can be operated manually or with air using the included two-piece handle and 4 ft. air hose with push-button trigger.
- Welded cylinder and frame enhance strength and service life
- Extra-thick base provides superior stability in harsh conditions
- Compact design fits a variety of heavy-duty lifting needs
- Chrome-plated piston resists rust and corrosion
- Includes overload protection via built-in safety valve
- Double spring design ensures safe, controlled descent
- Adjustable extension screw for precise height control
- Operates using air or manual two-piece handle
- 4 ft. swivel air hose with 1/4 in. NPT air trigger and airflow latch
- Heavy-duty chrome-plated air motor with wear-resistant parts
Prop 65 Warning
WARNING: This product can expose you to chemicals including Lead which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Specifications
- Capacity: 20 Ton (40,000 lbs.)
- Min. Height: 10 in.
- Max. Height: 20 in.
- Ram Travel: 6 in.
- Screw Adjustment: 4 in.
- Saddle Width: 1.75 in.
- Base Thickness: 1.25 in.
- Base Size (L x W): 8.875 x 5.75 in.
- Inner Package Dimensions: 10.5 x 8.125 x 11.5 in.
- Outer Package Dimensions: 10 x 8 x 11 in.
- Net Weight: 41 lbs.
- Gross Weight: 42 lbs.
- Air Inlet Fitting: 1/4 in. NPT
- Air Pressure: 110–125 psi
- Warranty: 1-Year
- UPC: 816904024871
