Air Lift and Support
MAHLE CLS-15 | 15 ton Commercial Vehicle Air Lift and Support Stand
- VENDOR:- MAHLE
- SKU# CLS-15
Description
MAHLE CLS-15 - 15 ton Commercial Vehicle Air Lift and Support Stand
Part Number: 485 80018 00
- Built-in vehicle support stand feature
- 100% air operated
- Removable handle along with two wheels allows ease in spotting and portability
- Optional air valve tee connector available
Specifications
- Capacity 30,000 lb (13,608 kg)
- Minimum Start Height 17.6 in (45 cm)
- Maximum Lift Height w/ Extension 52.3 in (133 cm)
- Maximum Lift Height w/o Extension 37.3 in (95 cm)
- Cylinder Bore 14 in (36 cm)
- Required Air Pressure 200 psi (13.8 bar)
- Overall Length w/ Handle 58.5 in (149 cm)
- Overall Length w/o Handle 25.5 in (65 cm)
- Wheel Diameter 5 in (13 cm)
- Stroke 10 in (25 cm)
- Inside Saddle Width 4.8 in (12 cm)
- Overall Saddle Width 5.5 in (14 cm)
- Extension Tubes Square
- Handle Length 36.5 in (93 cm)
- Shipping Weight 230 lb (104 kg)
Shipping
SHIPPING QUOTE
This Item requires you to fill out a "SHIPPING QUOTE FORM", Please read instructions carefully and fill out all applicable questions. An email will be sent to us with your items you intend to purchase and the shipping address. We will give you our best Freight rate to your "COMMERCIAL BUSINESS ADDRESS".
Once we receive a quote from the carrier we will email you with a full break down of price for cost of items, Sales Tax and Shipping Cost. At this point if you are happy with the price you will be able to click on a link in the email and it will go straight to our secure site were you can check out securely. If for any reason you need assistance or have concerns that need to be addressed please don't hesitate to call us directly at 706-478-0072. We will be more than happy to assist you.
