RTi R750HD-G Heavy Duty Air Regulator with Gauge, 3/4 in. NPT, 0–120 PSI
RTi R750HD-G Heavy Duty Air Regulator with Gauge, 3/4 in. NPT, 0–120 PSI
BRAND: RTi
SKU: R750HD-G
In Stock
Couldn't load pickup availability
Reading Technologies R750HD-G Heavy Duty Air Regulator with Gauge, 3/4 in. NPT, 0–120 PSI
Part Number: R750HD-G
The RTi R750HD-G is a heavy-duty 3/4 in. NPT air regulator built for high-flow industrial applications. Featuring a rugged anodized aluminum body, chemically-resistant Buna-N diaphragm, and tee handle knob, this unit ensures precise and reliable pressure control across a wide operating range. Includes a 0–120 PSI gauge for real-time monitoring.
Applications:
- Paint booths and high-volume compressed air systems
- Industrial tool setups and manifolds
- Regulated air delivery for filtration and drying stations
Designed for reliability and long service life, the R750HD-G can also be paired with optional tamper-proof lockout accessories for enhanced safety and control.
Prop 65 Warning
WARNING: This product can expose you to chemicals including Lead which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
- Part Number: R750HD-G
- Inlet/Outlet Port Size: 3/4 in. NPT
- Pressure Range: 10–130 PSI
- Maximum Supply Pressure: 250 PSI
- Flow Capacity: 175 SCFM
- Gauge: Included, 0–120 PSI (replaceable with KSG-008)
- Material: Anodized aluminum body with Buna-N diaphragm
- Relieving Type: Yes, with tee handle knob
- Max Operating Temperature: 175°F
- Weight: 3.2 lb
- Dimensions: 3.8 in. Diameter x 6.8 in. Height
- Optional Accessories: Lockout valve (R750HD-LO), Lock assembly (R750HD-TLK), Repair kit (R750HD-RK)
