Samson 535 811 - PM35 - 8:1 55 gal Drum Oil Pump

Samson 535 811 - PM35 - 8:1 55 gal Drum Oil Pump

Ships within (1 - 3 Business Days)

SKU: 535811

Regular price $1,385.59 USD
$1,385.59 USD
Shipping calculated at checkout.
Total:
Quick Question
Samson 535 811 - PM35 - 8:1 55 gal Drum Oil Pump - Tire Equipment Supply

Samson 535 811 - PM35 - 8:1 55 gal Drum Oil Pump

$1,385.59

Description

Samson 535 811 - PM35 - 8:1 55 gal Drum Oil Pump

Part No.  535811

Double acting air operated high pressure and reliable delivery pump for oil distribution applications. Built in port for optional (PN 609 008) pressure relief valve. Cast iron pump body for high pressure operation.

Fluids Handled
Synthetic and mineral based oil
Transmission fluid
Hydraulic oil
Gear lube
Corrosion Protection Fluids

Specifics
  • Pump Pressure Ratio 8:1
  • Continuous Duty Flow Rate 1.9 gpm (7 l/min)
  • Maximum Free Flow Rate 4.5 gpm (17 l/min)
  • Air Pressure Operating Range 30-175 psi (2-12 bar)
  • Maximum Outlet Pressure 1,400 psi (96 bar)
  • Air Motor Effective Diameter 3.15" (80 mm)
  • Air Motor Stroke 3.15" (80 mm)
  • Air Consumption 12.4 scfm (350 NL/min)
  • Air Inlet 3/8" NPTF
  • Fluid Inlet 1" NPTF
  • Fluid Outlet 1/2" NPTF
  • Wetted Materials Cast Iron, Steel, NBR, Polyurethane, Hard chromed steel
  • Noise Level 80 dB
  • Application Stub pump with bung, stub pump, 55 gal drum
  • Simultaneous Dispense Points 1-2
  • Max. Line Length 650' (200 m)
  • Pump Description Heavy Duty High Pressure

Shipping Weight: 55 lbs

Dimensions: 49 X 8 X 19 inches

Prop 65 Warning

WARNING: This product can expose you to chemicals including Lead which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
